Technical Specifications Mixed multi‑channel analog and digital signal input. Auxiliary power 24 V DC, typical power consumption 5.8 W. Operating temperature ‑10 ℃ to +55 ℃, storage temperature ‑40 ℃ to +85 ℃, non‑condensing relative humidity 5%‑95%. Conformal coated circuit board, isolation voltage 1800 V AC.
Functional Features Acquires analog measurement and digital status signals from field site. Completes signal filtering, conditioning and galvanic isolation. Transmits processed signals to main controller via back‑plane bus. On‑board LED displays each channel operating status. Built‑in hardware self‑diagnosis detects signal loop breakage and short‑circuit faults.
Application Scenarios Replacement spare‑part for ABB DCS and industrial control rack systems. Applied in power, petrochemical and metallurgy industry automation projects for maintenance and spare‑part upgrade.
Performance Parameters Low‑distortion signal processing ensures measurement accuracy. Galvanic isolation eliminates ground loop interference. Self‑diagnosis provides clear fault indication for field signal loops.
Material Composition Multilayer glass‑fiber epoxy printed circuit board. Signal conditioning circuits, optocoupler isolation assemblies. Conformal protective coating. Back‑plane plug‑in connectors and field signal wiring terminals.
Structural Characteristics Plug‑in circuit board adapting to standard cabinet rack slot. Board edge equipped with back‑plane bus connector and field signal terminals. Reserved mechanical fixing holes. Weight approximately 0.60 kilogram.
Working Principle After power‑on, the board completes hardware self‑initialization. Field input signals go through filtering, conditioning and optocoupler isolation. Valid signal data is transmitted to main controller over back‑plane bus. Internal diagnosis circuit monitors real‑time status of every signal channel.
Installation Requirements Disconnect rack auxiliary power before replacement. Insert YPI105C into corresponding slot and tighten fixing screws. Ensure back‑plane connector is fully locked. Complete field‑side signal wiring. Restore power supply and carry out channel signal verification test.
Usage Notes Follow anti‑static operation requirements during handling. Avoid damage to conformal coating. Hot‑plug under powered state is prohibited. Check field signal cable integrity during periodic overhaul.
