Technical Specifications Identical analog performance specifications to original measurement board; same channel count and resolution; matched input sensitivity; industrial temperature range.
Functional Features Drop-in replacement for original analog board; maintains measurement accuracy; fully compatible with system processing; field serviceable.
Application Scenarios Vibration monitoring module repair, analog measurement system maintenance, industrial instrumentation spare parts.
Performance Parameters Same measurement accuracy and drift characteristics as original; stable signal conditioning; low noise performance.
Material Composition Precision analog circuit board, high-stability electronic components, gold-plated connectors, conformal coating.
Structural Characteristics Same mechanical dimensions as original board; standard connector interface; mounting hole alignment.
Working Principle Replaces the faulty analog front-end board in the measurement module, restoring accurate signal conditioning and measurement functionality.
Installation Requirements Disassemble module following service manual; discharge all capacitors before handling; perform calibration after replacement.
Usage Notes Handle with ESD precautions; calibrate measurement channels after replacement; store in anti-static packaging.
