Technical Specifications Supports dedicated Advant bus communication, standard backplane installation, 24V DC power supply, industrial operating temperature range.
Functional Features Realizes high-speed data transmission between controller and field I/O modules. Provides bus signal isolation and fault diagnosis function.
Application Scenarios ABB Advant DCS distributed control system, power plant, chemical and petrochemical process control.
Performance Parameters Stable bus transmission, built-in fault indicator, support hot swap under qualified system condition.
Structural Characteristics Standard module form for rack installation, metal casing, backplane connector for signal and power connection.
Working Principle Transmits control commands and process data between the controller and field stations via internal system bus, monitors communication status in real time.
Installation Requirements Install on designated rack slot. Ensure correct backplane connection. Use specified power source.
Usage Notes Do not plug or unplug module when power is on. Check LED status for communication faults. Configure parameters via ABB DCS configuration tool.
