Technical Specifications Multi‑channel high‑precision analog sampling input, multi‑group pulse trigger output, multiple communication interfaces. Auxiliary power supply 24 V DC, typical power consumption 14 W. Operating temperature ‑10 ℃ to +55 ℃, storage temperature ‑40 ℃ to +85 ℃, non‑condensing relative humidity 5%‑95%. Protection grade IP20 for cabinet‑inside installation.
Functional Features Samples generator terminal voltage, stator current and rotor feedback signals. Executes multiple excitation closed‑loop regulation algorithms. Outputs trigger pulse for thyristor power unit. Supports multiple communication protocols for upper system connection. Rich fault recording and event logging function.
Application Scenarios Widely applied in thermal power plants, hydropower stations and large‑scale industrial self‑power plants for medium‑and‑large generator excitation control. Used for new project construction, system renovation and spare‑part replacement.
Performance Parameters High‑speed regulation response adapts to various generator operating conditions. High‑precision sampling guarantees excitation control accuracy. Large‑capacity memory stores abundant fault event data.
Material Composition Metal‑plastic composite rack‑mount housing. Internal multilayer glass‑fiber epoxy printed circuit boards set. Industrial‑grade main processor, high‑precision sampling modules. Screw‑type high‑density signal terminals, communication ports and power supply terminals.
Structural Characteristics Standard 19‑inch rack‑mount controller structure. Front panel is equipped with LED status indicators, operation keys and communication ports. Rear panel arranges power supply, analog sampling, pulse output and signal wiring terminals.
Working Principle After power‑on, controller finishes hardware self‑check and parameter loading. It continuously collects generator voltage and current feedback signals. Main processor executes excitation regulation algorithm according to set control parameters, outputs trigger pulse to adjust thyristor conduction angle, so as to realize closed‑loop adjustment of generator excitation current. Operating data and fault events are stored locally, meanwhile uploaded to upper monitoring system through communication interface.
Installation Requirements Mount UNITROL1000 onto standard 19‑inch cabinet rack and fasten fixing screws. Complete auxiliary power supply, analog sampling, pulse output and communication wiring strictly following engineering schematic.
