Technical Specifications Multi‑channel screw‑type signal terminals, auxiliary power distribution terminals. Operating temperature 0 ℃ to +60 ℃, storage temperature ‑40 ℃ to +85 ℃, non‑condensing relative humidity 5%‑95%. Protection grade IP20 for cabinet internal application. Fully compatible with S800 series I/O modules mechanical and electrical standards.
Functional Features Offers field‑side wiring interface for I/O signal loops. Transmits signal between field cables and inserted I/O modules. Implements back‑plane bus signal routing. Equipped with reinforced mechanical locking mechanism for I/O modules. Supports hot‑swap operation under system permitted conditions.
Application Scenarios Deployed in power plant, petrochemical and metallurgical DCS automation systems. Serves as matching base for S800 I/O modules for new project construction and field spare‑part replacement.
Performance Parameters Low and stable terminal contact resistance. Mechanical locking structure avoids loose contact caused by vibration. Signal transmission maintains stability under long‑term continuous operation.
Material Composition Glass‑fiber epoxy multilayer printed circuit board. Reinforced flame‑retardant plastic housing. Copper‑alloy screw wiring terminals. Back‑plane plug‑in contact components.
Structural Characteristics Standard rack‑mount base structure. Front section arranges field signal wiring terminals. Upper slot is used for inserting matching I/O module. Rear side connects rack back‑plane bus. Weight approximately 0.41 kilogram.
Working Principle Field analog and digital signals access the screw terminals of TB840A. Signals pass internal printed circuit board and are delivered to plugged I/O module through slot contact points.
Installation Requirements Fix TB840A base to designated DCS rack position and tighten mounting screws. Complete field signal cable wiring strictly according to engineering drawings. Ensure reliable cabinet protective grounding. Insert compatible I/O module into slot and engage locking buckle.
Usage Notes Prevent metal debris and conductive dust from falling into terminal area. Inspect terminal tightening torque periodically. Confirm I/O module model matches TB840A specification. Avoid continuous exposure to corrosive gas environment.
