Technical Specifications Built‑in logic processing unit, multi‑channel I/O support, communication interface. Auxiliary power supply 24 V DC. Typical power consumption 5.2 W. Operating temperature 0 ℃ to +60 ℃, storage temperature ‑40 ℃ to +85 ℃, non‑condensing relative humidity 5%‑95%. Module surface IP20. Meets industrial controller relevant standards.
Functional Features Executes user‑configured control logic program. Realizes data interaction with I/O modules. Supports data communication with upper host monitoring system. Front‑panel LED reflects running, stop and fault status. Built‑in hardware self‑diagnosis function.
Application Scenarios Applied for small‑size process control, auxiliary equipment automatic control. Widely used in water treatment, light industry and small‑scale chemical projects. Used for project construction and spare‑part replacement.
Performance Parameters Logic program executes with stable cycle. Hardware self‑diagnosis can capture internal circuit fault. Communication interface maintains stable data transmission. LED status indication is accurate.
Material Composition Multilayer glass‑fiber epoxy printed circuit board. Industrial grade main processing chip, communication circuit components. Reinforced plastic housing. Screw‑type wiring terminals. Copper alloy back‑plane connector contact pieces.
Installation Requirements Insert module into control cabinet rack slot and tighten locking screw. Connect 24 V DC auxiliary power supply. Complete back‑plane bus connection. Guarantee cabinet protective grounding. Verify running LED status after power‑on, download user control program.
Usage Notes Anti‑static protection is required in handling process. Hot‑swap under powered condition is forbidden.
