Technical Specifications Industrial‑grade processor core. Configured with program memory and data memory. 24 V DC power supply. Operating temperature range 0 ℃‑60 ℃. Supports system internal bus communication.
Functional Features Executes user control logic program. Realizes data interaction with I/O modules. Supports fault self‑diagnosis. Provides data retention upon power failure. Supports online system configuration download.
Application Scenarios Main controller for factory automation, water treatment and light‑industry DCS system. Installed in standard control cabinet rack.
Performance Parameters Stable real‑time scanning cycle for process control. Internal fault point can be uploaded to monitoring system. Supports system diagnosis information output.
Material Composition Glass‑fiber epoxy circuit board. Industrial semiconductor chips. Gold‑plated backplane contact terminals. Flame‑retardant front panel housing.
Structural Characteristics Plug‑in rack‑mount structure. Front panel with multi‑function LED status lamps. Rear side connects to system backplane bus. Module dimension matches standard rack slot.
Working Principle After power‑on self‑check completes, the processor loads user application program. Reads field I/O data through backplane bus, completes algorithm and logic calculation, sends control output commands and communicates with upper monitoring station.
Installation Requirements Install to assigned rack processor slot. Confirm good backplane contact. Finish hardware configuration in engineering tool. Guarantee cabinet ventilation and heat dissipation.
Usage Notes Adopt anti‑static measure when handling module. Backup project program periodically. Forbid hot‑swap when system does not permit. Check indicator lamp status in daily maintenance. Power off before removing module.
