Technical Specifications Equipped with dedicated industrial CPU chip. Contains fixed capacity working memory and program memory. Working voltage 24 V DC. Operating temperature 0 ℃‑60 ℃. Supports system backplane bus.
Functional Features Runs user‑configured control application program. Collects and processes I/O signal data. Executes logic calculation and interlock control. Supports system communication with I/O modules and upper host. Has power‑fail data retention function.
Application Scenarios Serves as main control unit in industrial DCS cabinet. Applied in power plant, chemical industry and manufacturing process automation.
Performance Parameters Real‑time program cycle meets industrial control timing requirement. Supports system redundancy configuration. Built‑in diagnostic function detects module internal fault.
Material Composition High‑grade industrial printed circuit board. Industrial CPU and memory chips. Gold‑plated backplane contact pins. Flame‑retardant plastic front panel.
Structural Characteristics Rack plug‑in module form. Front panel fitted with status LED indicators. Rear connector connects to control system backplane. Standard size for system rack slot.
Working Principle After power‑on, module completes self‑diagnosis, loads user control program from memory. Collects field I/O data via backplane bus, performs logic computation, outputs control instruction and exchanges data with upper monitoring system.
Installation Requirements Insert into designated processor slot of system rack. Ensure reliable backplane contact. Complete system configuration download after installation. Guarantee cabinet heat dissipation condition.
Usage Notes Implement static protection before contact module. Do not hot‑swap in non‑allowable system state. Backup application program regularly. Observe LED fault indicator during operation. Cut off power supply before disassembly.
