Technical Specifications Industrial shielded multi‑conductor cable structure. Matches dedicated bus connector. Working temperature covers industrial cabinet ambient range. Shielding performance meets EMC industrial standard.
Functional Features Transmits control bus differential signal. Integral shielding restrains external electromagnetic interference. Pre‑terminated connector reduces on‑site wiring error. Ensures stable high‑speed signal transmission.
Application Scenarios Internal interconnection of DCS controller racks. Connection between adjacent I/O racks. Used in power, chemical and pulp‑paper automation control cabinets.
Performance Parameters Characteristic impedance conforms to system bus requirement. Shielding coverage reaches high proportion. Connector maintains stable contact performance under long‑term vibration environment.
Material Composition Inner conductor uses oxygen‑free copper. Insulation layer adopts high‑performance polymer material. Outer layer includes metal shielding net and outer protective sheath. Connector shell uses metal alloy.
Structural Characteristics Finished cable with both ends assembled with dedicated plug‑in connectors. Integrated shielding layer runs through whole cable length. Compact connector structure fits module interface.
Working Principle Differential control signal transmits along inner conductors. Metal shielding layer suppresses external electromagnetic noise interference, guarantees signal integrity during transmission process.
Installation Requirements Lay cable inside control cabinet, avoid parallel arrangement with high‑power power cable. Keep reasonable bending radius. Lock connector firmly after insertion. Reserve proper cable slack.
Usage Notes Do not pull cable with excessive force. Avoid sharp scratch on outer sheath. Prevent connector pins from bending. Regularly check connector locking state during equipment maintenance.
