Technical Specifications Model: NTR002 Output Channels: 8 relay output channels Contact Rating: Resistive load rated switching capacity Isolation Mode: Relay contact galvanic isolation Mounting Mode: Rack plug‑in installation Power Supply: Powered by rack back‑plane bus Operating Temperature: 0 ℃ to +60 ℃ Storage Temperature: ‑40 ℃ to +85 ℃ Relative Humidity: 5‑95 %, non‑condensing Protection Class: IP20 Certifications: CE
Functional Features Eight‑channel relay contact output for controlling field switching loads. Galvanic isolation between control system side and field load loop via relay contacts. Front‑panel LED indicators show each relay channel actuation status. Back‑plane bus receives control commands from main controller. Built‑in self‑diagnosis monitors module power‑on and internal hardware fault.
Application Scenarios Spare‑part replacement for NTR002 relay output module in ABB legacy control rack. Field interlock signal output, indicator light control and intermediate relay driving for industrial process control system. Hardware maintenance and renewal of old‑generation ABB automation equipment.
Working Principle NTR002 obtains operating power from rack back‑plane bus. Digital control commands from main controller are transmitted to module via back‑plane bus. Driving circuit energizes corresponding relay coil, relay contact acts and completes on‑off control of field load loop. LED indicator lights up when relay channel is actuated. Relay contact provides complete galvanic isolation between control system and field side. Self‑diagnosis circuit monitors module hardware abnormality.
Installation Requirements Insert NTR002 fully into designated rack slot and tighten front‑panel locking screw. Connect field load loop cables to front‑side relay contact terminals, strictly comply with contact rated load specification. Complete protective earthing according to cabinet grounding specification. Ambient operating temperature shall keep within 0 ℃ to +60 ℃ without condensation. Verify each relay channel switching output function after power‑on.
