Technical Specifications Model: NTMP01 Processing Core: Industrial dedicated processor unit Memory: On‑board working memory and fault data storage memory Mounting Mode: Rack plug‑in installation Power Supply: Powered by rack back‑plane bus Operating Temperature: 0 ℃ to +60 ℃ Storage Temperature: ‑40 ℃ to +85 ℃ Relative Humidity: 5‑95 %, non‑condensing Protection Class: IP20 Certifications: CE
Functional Features Executes auxiliary logic calculation and data pre‑processing to reduce main controller operation load. Completes I/O signal pre‑treatment, alarm event sorting and data forwarding function. On‑board memory stores configuration parameters and fault event records. Front‑panel LED indicators display module power‑on, running and fault status. High‑speed data exchange with main controller via rack back‑plane bus. Module self‑diagnosis monitors internal processor, memory and bus communication fault.
Application Scenarios Spare‑part replacement for NTMP01 processor module in ABB legacy control rack system. Auxiliary data processing for metallurgy, chemical industry automation control projects. Hardware repair and component renewal of old ABB automation platform.
Working Principle NTMP01 obtains power supply from rack back‑plane bus. It receives original I/O data and configuration commands sent by main controller, completes auxiliary logic calculation and data pre‑processing, and returns processed result data to main controller through back‑plane bus. On‑board memory saves configuration parameters and fault event information. LED indicators reflect module running and fault status. Self‑diagnosis circuit detects processor, memory and bus communication abnormality.
Installation Requirements Insert NTMP01 fully into target rack slot and tighten front‑panel locking screw. Download corresponding application configuration parameters after power‑on. Reserve heat‑dissipation space around module slot. Ambient operating temperature shall maintain within 0 ℃ to +60 ℃ without condensation. Verify data interaction function between NTMP01 and main controller after commissioning.
