Technical Specifications Control signal input interface, multi‑channel power unit feedback signal terminals. Auxiliary power 24 V DC, typical power consumption 5.1 W. Operating temperature 0 ℃ to +60 ℃, storage temperature ‑40 ℃ to +85 ℃, non‑condensing relative humidity 5%‑95%. Conformal coated printed circuit board.
Functional Features Receives control commands from drive main control board. Transmits drive signals to inverter power units. Collects temperature and fault feedback signals from power modules. On‑board LED indicates signal transmission and hardware fault status. Built‑in hardware self‑diagnosis detects feedback circuit and communication faults.
Application Scenarios Power interface spare part for ABB medium‑large frequency converter. Used for industrial transmission equipment overhaul in metallurgy, water supply and chemical industry.
Performance Parameters Reliable bidirectional signal transmission between control and power section. Fast fault feedback response speed. Stable continuous operating performance.
Material Composition Multilayer glass‑fiber epoxy printed circuit board. Signal isolation, amplification and conditioning assemblies. Conformal protective coating. Internal plug‑in connectors and signal wiring terminals.
Structural Characteristics Cabinet fixed‑mount circuit board. Equipped with multi‑group internal signal connectors. Reserved mechanical fixing holes. Weight approximately 0.50 kilogram.
Working Principle Control commands from main board are received and processed, then forwarded to inverter power units. Temperature and fault feedback signals from power components are collected and sent back to main controller. Diagnosis circuit continuously monitors signal transmission channel operating condition.
Installation Requirements Fully cut off converter main power and discharge internal high‑voltage capacitors before replacement. Fasten NINT‑72C to designated cabinet mounting position. Complete all internal plug‑in connections. Restore power supply, perform power unit signal test and equipment running verification.
Usage Notes Strictly implement electrostatic protection requirements. Confirm all connectors are fully inserted. Do not scratch conformal coating surface. Check inverter unit fault feedback function after replacement.
