Technical Specifications Model: KX8974c V24 Reference Part Code: HIEE320606R1 Supply Voltage: 24 VDC Channel Configuration: Multi‑group configurable digital input / output and analog signal processing channels Back‑plane Connector: Standard industrial rack gold‑plated multi‑pin connector Signal Interface: HE10 ribbon‑cable interface for field peripheral wiring Galvanic Isolation: Channel‑to‑back‑plane galvanic isolation Operating Temperature: ‑20 ℃ to +70 ℃ Storage Temperature: ‑40 ℃ to +85 ℃ Relative Humidity: 5‑95 %, non‑condensing Protection Class: IP20 Certifications: CE
Functional Features Multi‑channel digital and analog signal conditioning and level conversion for field peripheral signals. Galvanic isolation between field signal side and system back‑plane bus restrains ground‑loop interference. HE10 flat ribbon‑cable interface simplifies multi‑point field wiring work. On‑board signal sampling circuit converts physical signal into digital data for main controller processing. Hardware over‑voltage and over‑current protection for each signal channel. Front‑panel LED indicators show module power‑on and channel fault status. Back‑plane bus completes data exchange with system main processor.
Application Scenarios Spare‑part replacement for KX8974c V24 interface board in ABB legacy control rack. Peripheral signal interface for power plant, metallurgy old‑generation automation equipment. Hardware maintenance and component renewal for retired ABB industrial control system.
Installation Requirements Insert KX8974c V24 fully into target rack slot and fasten front locking screw. Connect field peripheral signal ribbon‑cable to HE10 interface according to signal definition. Implement protective earthing complying with control‑system grounding specification. Reserve ventilation heat‑dissipation clearance around circuit‑board slot. Ambient operating temperature shall keep within ‑20 ℃ ~ +70 ℃ without condensation. Verify each channel signal acquisition function after hardware installation completion.
