Technical Specifications Model: HN810A Signal Type: 24 V DC digital input and digital output Channel Configuration: Multi‑channel mixed DI / DO Mounting Style: Control rack plug‑in module Power Supply: From rack back‑plane bus Operating Temperature: 0 ℃ to +60 ℃ Storage Temperature: ‑40 ℃ to +85 ℃ Relative Humidity: 5‑95 %, non‑condensing Protection Class: IP20 Certifications: CE
Functional Features Multi‑channel mixed digital input and digital output for field discrete signal collection and control. Group‑wise galvanic isolation eliminates ground‑loop interference between field side and control system. Built‑in over‑current protection for output channels to prevent module damage caused by field loop short‑circuit. Front‑panel LED indicators show per‑channel signal status and module fault alarm information. On‑board self‑diagnosis detects channel open‑circuit, back‑plane power supply anomaly and internal circuit fault. Supports authorized hot‑swap operation under system maintenance workflow.
Application Scenarios Spare‑part replacement for HN810A I/O module in industrial control rack. Signal acquisition and control for limit switches, proximity sensors, intermediate relays and solenoid valves. Discrete signal processing for power, chemical and manufacturing automation projects.
Installation Requirements Insert HN810A into designated rack slot and lock side locking buckle. Complete connection between module and corresponding field termination hardware. Implement protective earthing complying with system grounding specification. Reserve ventilation heat‑dissipation space around module slot. Ambient operating temperature shall keep within 0 ℃ ~ +60 ℃ without condensation. Complete channel parameter configuration through engineering software after hardware installation.
Usage Notes Field signal cables adopt shielded twisted‑pair and implement single‑point shielding earthing. Do not exceed rated load current for digital output loops.
