Technical Specifications Model: HBS01‑EPD Interface: RJ45 Ethernet port, 10/100 Mbps auto‑negotiation Supported Protocols: Standard industrial Ethernet protocols Mounting Mode: DIN‑rail TS35 mounting Power Supply: 24 V DC Operating Temperature: 0 ℃ to +60 ℃ Storage Temperature: ‑40 ℃ to +85 ℃ Relative Humidity: 5‑95 %, non‑condensing Protection Class: IP20 Certifications: CE
Functional Features 10/100 Mbps auto‑negotiation Ethernet interface for industrial network data transmission. Protocol conversion function realises data interaction between field process devices and host control system. Front‑panel LED indicators show power‑on, network link, data‑transmission and fault‑alarm status. Built‑in hardware self‑diagnosis monitors power supply, network link and internal circuit faults. Compact DIN‑rail structure adapts to limited installation space inside automation cabinet.
Application Scenarios Spare‑part replacement for HBS01‑EPD communication module in industrial control cabinet. Ethernet data interconnection for distributed intelligent field devices in process industry. Automation project modification adding Ethernet communication function for legacy field equipment.
Working Principle HBS01‑EPD is powered by external 24 V DC control power supply. It receives data packets from upper‑level control system via RJ45 Ethernet port, executes protocol parsing and conversion, and forwards processed data to connected field process devices. Data uploaded from field devices is encapsulated into standard Ethernet protocol frames and transmitted to upper‑level system.
Installation Requirements Clip HBS01‑EPD firmly onto standard TS35 DIN‑rail inside control cabinet. Connect 24 V DC power‑supply cable to front screw‑clamp terminals and tighten terminals to specified torque. Connect industrial‑grade shielded Ethernet cable to front‑panel RJ45 port. Implement protective earthing complying with automation system grounding specification.
