Technical Specifications Model: FIS‑13 Communication Standard: PROFIBUS‑DP Baud Rate Range: Up to 12 Mbit/s auto‑detect Mounting Mode: DIN‑rail TS35 mounting inside MCC cabinet Power Supply: 24 V DC Operating Temperature: ‑5 ℃ to +55 ℃ Storage Temperature: ‑40 ℃ to +70 ℃ Relative Humidity: 5‑95 %, non‑condensing Protection Class: IP20 Certifications: CE, cULus
Functional Features Works as PROFIBUS‑DP slave station for motor‑control equipment fieldbus connection. Collects digital status, fault signal and analog measuring data from matched motor‑control units. Receives remote start‑stop and reset control commands from PROFIBUS‑DP master station. Galvanic isolation exists between PROFIBUS‑bus side and motor‑unit internal circuit. Front‑panel LED indicators show power‑on, bus‑communication and fault‑alarm status. Compact slim‑body design occupies minimum installation space inside MCC cabinet.
Application Scenarios Spare‑part replacement for FIS‑13 fieldbus slave module inside ABB MCC cabinet. Fieldbus remote monitoring and remote control for motor starters and soft‑starters in industrial motor‑control center. Retrofit project adding PROFIBUS‑DP communication function for legacy ABB motor‑control equipment.
Installation Requirements Clip FIS‑13 onto standard TS35 DIN‑rail inside MCC cabinet. Connect PROFIBUS‑DP shielded bus cable, 24 V DC power‑supply cable and motor‑unit signal cable to front screw‑clamp terminals, tighten terminals to specified torque. Set unique PROFIBUS‑DP slave station address via module address dial switch. Install bus terminal resistance at physical tail‑end of PROFIBUS‑DP trunk cable. Implement protective earthing complying with MCC cabinet grounding specification. Ambient operating temperature shall keep within ‑5 ℃ ~ +55 ℃ without condensation.
