Technical Specifications Processor: 32‑bit industrial‑grade CPU Program Memory: Flash memory for application program storage Data Memory: RAM for runtime variable data processing Local Bus Interface: Advant‑Master internal backplane bus Communication Interfaces: Serial communication ports, field‑bus interface expansion slots Operating Supply Voltage: 24 V DC ±10 % Operating Temperature: 0 ℃ to +60 ℃ Storage Temperature: ‑40 ℃ to +85 ℃ Relative Humidity: 5‑95 %, non‑condensing Mounting Type: Advant‑Master rack plug‑in module Protection Class: IP20 Certifications: CE
Functional Features Executes cyclic industrial‑control application programs for process‑logic control. Realizes data interaction with I/O modules through internal rack backplane bus. Supports multiple communication‑interface expansions for connection with HMI and field‑bus equipment. Built‑in hardware watchdog monitors controller running status and triggers fault‑protection actions upon program‑abnormality conditions. Front‑panel LED indicator group displays power‑on, run, fault and communication status. Supports program online download and upload via dedicated configuration tool. Stores fault log and system diagnostic information inside module memory. Hot‑swap support for online replacement in redundant‑system configurations.
Installation Requirements Insert AX670 controller module into designated slot of Advant‑Master standard rack. Complete cabinet protective‑earthing complying with official system‑grounding specifications. Connect external communication‑cables using shielded twisted‑pair cables; separate signal cables and high‑power power cables. Reserve sufficient ventilation‑space around the module for heat dissipation. Tighten spring‑clip locking buckle to guarantee good golden‑finger contact. Ambient operating environment must stay within rated temperature‑humidity ranges without condensation.
