Technical Specifications
Manufacturer: ABB
Model: 83SR04 / 83SR04E
Product Code: GJR2390200R1310
Control Type: Binary (on/off) with optional analog function
Outputs: 4 binary outputs
Analog Option: 1 to 4 analog control options
Programming: Stored-program binary and analog control
Input Voltage: 24 V DC (typical)
Mounting: DIN rail or 19-inch rack
Communication: ABB proprietary DCS bus
Dimensions: 198 × 261 × 20 mm (L × H × W)
Weight: 0.55 kg
Operating Temperature: 0 to +60 °C
Storage Temperature: -25 to +70 °C
Functional Features
High-speed deterministic binary output operation with minimal latency. Flexible integration with ABB Symphony and Harmony systems for seamless DCS/PLC configuration. Compact 20 mm width enables high-density mounting. Built-in diagnostics provide real-time fault detection and system health monitoring. Stored-program architecture supports user-defined sequences, reducing reliance on external relays.
Application Scenarios
Turbine logic interlocking and breaker command control in power plants. Control valve, damper, and signal relay driving in water/wastewater treatment. Solenoid-based fluid control and logic sequencing in pharmaceutical automation. Conveyor direction, actuator logic, and motor start/stop control in material handling. Line-level logic execution integrated with SCADA in manufacturing automation.
Installation and Usage Notes
Mount on a 35 mm DIN rail or in a 19-inch rack per the cabinet layout. Connect the 24 V DC supply observing polarity. Wire the 4 binary outputs to the field devices per the I/O diagram. Download the stored program logic via the DCS engineering tool. Verify output operation and diagnostic LEDs during commissioning. Observe the module’s country-specific compliance markings regarding RoHS status.
