Technical Specifications Multi‑pair shielded signal conductor structure, dedicated locking connectors assembled at both ends. Operating temperature ‑20 ℃ to +70 ℃, storage temperature ‑40 ℃ to +85 ℃. Wear‑resistant and oil‑resistant outer sheath.
Functional Features Transmits operation command signals from teach pendant to robot controller. Transmits robot real‑time running status and alarm data back to teach pendant. Multi‑layer shielding structure suppresses industrial site electromagnetic interference. Dedicated locking connectors prevent accidental disconnection during manual operation.
Application Scenarios Teach pendant cable spare part for ABB industrial robot. Used for cable wear, aging and damage replacement during robot on‑site debugging and maintenance work.
Performance Parameters Low signal transmission distortion. Excellent anti‑electromagnetic‑interference performance. Stable connector locking performance under frequent plug‑and‑pull condition.
Material Composition Twisted‑pair shielded signal conductors. Insulation layer, overall shielding layer. Wear‑resistant flexible outer sheath. Precision molded locking connectors at both ends.
Structural Characteristics Finished integrated cable assembly with fixed length. Both‑end equipped with dedicated robot teach‑pendant connectors. Weight approximately 0.48 kilogram.
Working Principle Operation and programming signals generated by teach pendant are transmitted to robot control cabinet through shielded conductors.
Installation Requirements Confirm robot cabinet power is disconnected before replacement. Unplug old cable from teach pendant and cabinet port. Install 3HAC029818‑00110, fully lock connectors at both ends.
Usage Notes Avoid sharp scratch and heavy extrusion on cable outer sheath. Prevent excessive tensile force on cable and connectors. Check cable surface abrasion and connector locking status in regular robot maintenance.
