Technical Specifications Main power input interface, multi‑group isolated power output branches. Auxiliary control power 24 V DC. Operating temperature 0 ℃ to +55 ℃, storage temperature ‑40 ℃ to +85 ℃, non‑condensing relative humidity 5%‑95%. Integrated over‑voltage, over‑current and short‑circuit protection functions.
Functional Features Processes main power input of robot cabinet. Distributes multiple groups of stable power for internal robot functional units. Independent protection for each power output branch. On‑board LED indicates power running and fault alarm status. Built‑in hardware self‑diagnosis detects output overload and internal circuit abnormality.
Application Scenarios Power distribution spare part for ABB industrial robot controller. Applied for robot cabinet power assembly maintenance and replacement in automated production lines.
Performance Parameters Reliable multi‑branch power distribution performance. Rapid fault cut‑off response under abnormal working conditions. Stable long‑duration continuous operation performance.
Material Composition Metal mounting housing. Power conversion circuit assemblies, protection fuse components, printed circuit board. Power input‑output terminal blocks.
Structural Characteristics Cabinet fixed‑mount integrated assembly. Equipped with power input terminals and multi‑channel output terminals. Mechanical fixing holes for cabinet installation. Weight approximately 1.85 kilogram.
Working Principle External input power flows into the assembly, goes through filtering and protection processing, and is assigned to each independent output branch. Each branch delivers required power to corresponding robot internal hardware. Protection circuit executes power cut‑off action when overload or short‑circuit occurs. Diagnosis circuit monitors power input and each branch output state continuously.
Installation Requirements Fully cut off robot cabinet main power before replacement. Fasten 3HAC025562‑00106 to cabinet designated mounting position. Complete main power input wiring and each branch output wiring. Restore power supply and verify each power branch output performance.
Usage Notes Confirm input voltage conforms to hardware specification before power‑on. Check terminal fastening condition in regular maintenance. Maintain good heat dissipation environment around assembly. Do not remove original protection devices.
