Technical Specifications Back‑plane bus interface, multi‑channel signal interaction interface. Auxiliary power 24 V DC, typical power consumption 8.9 W. Operating temperature ‑10 ℃ to +55 ℃, storage temperature ‑40 ℃ to +85 ℃, non‑condensing relative humidity 5%‑95%. Conformal coated printed circuit board.
Functional Features Runs core closed‑loop control algorithm for power equipment. Receives measurement feedback data from each signal board. Generates control commands and distributes to subordinate functional boards. Executes system fault judgment and protection logic. On‑board LED displays processor running and fault status. Built‑in hardware self‑diagnosis for processor and memory access abnormality. Conformal coating improves environmental adaptability.
Application Scenarios Core spare‑part for ABB high‑power excitation and power conversion control rack. Applied in power plant and heavy‑industry automation equipment overhaul work.
Performance Parameters High‑speed real‑time algorithm calculation capability. Reliable data interaction with each peripheral board. Accurate fault logic judgment ensures system safety operation.
Material Composition Multilayer glass‑fiber epoxy printed circuit board. Industrial‑grade processor chip, memory and peripheral logic assemblies. Conformal protective coating. Back‑plane plug‑in connectors.
Structural Characteristics Standard plug‑in circuit board matching control rack slot. Board edge equipped with back‑plane bus connector. Reserved mechanical fixing holes. Weight approximately 0.78 kilogram.
Working Principle After power‑on, the board completes hardware self‑test, memory initialization and system program loading. It receives feedback data from each measurement board via back‑plane bus. Internal processor executes control algorithm and protection logic, generates control commands and sends to corresponding functional boards. Diagnosis circuit monitors hardware running status continuously.
Installation Requirements Cut off rack auxiliary power supply before replacement. Insert 3BHE021951R0124 into corresponding slot and tighten fixing screws. Confirm back‑plane connector is fully locked. Restore power supply, download control configuration parameters and complete system function verification.
