Technical Specifications
Catalog identity KTS 01147.9. Supply voltage class 24 V AC or DC or 230 V AC depending on variant. Switching contact SPDT or SPST micro-switch. Temperature set band typically 0 to 60 C with fixed or adjustable knob. Contact rating around 5 A at 250 V AC resistive. Mounting clip for 35 mm DIN rail. Body material thermoplastic or aluminum cap. Weight about 0.1 kg. Operating temperature -20 to plus 80 C ambient cabinet air.
Functional Features
Bimetal or electronic sensing element opens and closes contact at setpoint. Controls fan coil, electric valve, cabinet heater or ventilation relay. UL and CSA listed.
Application Scenarios
Anti-condensation heater control in MV drive cabinets. Fan start-stop on temperature threshold. HVAC and panel climate control in industrial rooms.
Material and Structure
Thermoplastic housing, DIN clip, screw terminals, sensing bulb or bimetal strip, micro-switch contact block.
Working Principle
Temperature change deflects bimetal strip or shifts electronic comparator output, mechanically or electronically actuates the relay contact, switching the connected load on or off.
Installation Requirements
Mount on 35 mm DIN rail inside cabinet, keep sensor away from direct heat source, use copper conductors sized to contact rating, bond ground if metal bracket.
Usage Notes
Set hysteresis correctly to avoid contact chatter. Not for direct switching of high-current heaters without interposing contactor.
