Technical Specifications Multi‑channel analog input, supports 4‑20 mA and voltage signal types. Auxiliary power 24 V DC, typical power consumption 4.1 W. Operating temperature 0 ℃ to +60 ℃, storage temperature ‑40 ℃ to +85 ℃, non‑condensing relative humidity 5%‑95%. Galvanic isolation between field side and internal bus.
Functional Features Collects standard analog process signals from field site. Completes analog‑to‑digital signal conversion. Transmits digital process data to DCS main controller through back‑plane bus. Each channel corresponds to status LED indicator. Supports hardware self‑diagnosis for loop breakage and short‑circuit faults.
Application Scenarios Field signal acquisition spare‑part for ABB DCS system. Applied in power plant, chemical and petrochemical industry for temperature, pressure and flow signal collection.
Performance Parameters High‑precision analog‑digital conversion ensures measurement accuracy. Galvanic isolation reduces influence of field‑side electromagnetic interference. Self‑diagnosis provides accurate fault positioning for field signal loops.
Material Composition Flame‑retardant plastic module housing. Multilayer glass‑fiber epoxy printed circuit board. Signal conditioning and A/D conversion components. Back‑plane plug‑in connector and field wiring screw terminals.
Structural Characteristics Standard DCS plug‑in module structure. Front panel arranges channel status LED and field wiring terminals. Rear side equipped with back‑plane bus connector. Weight approximately 0.36 kilogram.
Working Principle Field analog signals enter module via front‑end screw terminals. Signals go through filtering and conditioning circuit. Analog‑digital conversion chip converts analog quantity into digital data. Digital data is transmitted to DCS main controller over back‑plane bus. Diagnosis circuit monitors signal loop condition in real‑time.
Installation Requirements Insert 3BDH000741R1 into designated slot of DCS rack and lock fixing latch. Complete field sensor signal wiring on front‑end terminals. Confirm back‑plane connector is fully engaged. Power on DCS system and perform channel signal acquisition test.
Usage Notes Adopt shielded cable for analog signal wiring. Separate signal cable from high‑voltage power cable. Check terminal tightening torque in regular maintenance.
