Technical Specifications Operating Supply Voltage: 24 VDC Signal Interface: Multi‑pin plug‑in industrial connector Operating Temperature: ‑20 ℃ to +60 ℃ Storage Temperature: ‑40 ℃ to +85 ℃ Relative Humidity: 5%‑95%, non‑condensing Mounting Mode: Internal device plug‑in installation Protection Grade: IP20 inside cabinet Certifications: CE
Functional Features Completes multi‑channel internal signal sampling and conditioning for host industrial equipment. Built‑in filter components restrain high‑frequency interference noise inside equipment. Realizes reliable signal interconnection between different functional units of host device. Adopts plug‑in mechanical structure for convenient on‑site disassembly and replacement. Maintains full mechanical and electrical compatibility with matched host equipment.
Application Scenarios Corresponding ABB drive or control equipment internal circuit‑board spare‑part replacement. Industrial automation equipment overhaul and maintenance project.
Installation Requirements Insert circuit‑board assembly into designated installation position inside host equipment. Follow host equipment protective earth grounding specification strictly. Confirm supply voltage matches rated specification before power‑on. Replacement operation must comply with on‑site electrical safety operation procedure. Ambient installation environment stays within defined temperature and humidity range without condensed moisture.
Usage Notes Do not apply voltage exceeding rated specification to connector pins. Control equipment internal dust accumulation to avoid connector contact failure. Inspect connector locking status during periodic maintenance work. Only adopt original matching spare‑part for equipment replacement. Implement lock‑out tag‑out safety procedure during host equipment internal maintenance.
