Technical Specifications On‑board Resource: Integrated CPU core, RAM and Flash memory Fieldbus Interface: CS31 fieldbus interface Communication Port: Serial communication port I/O Expansion: Support local and remote I/O expansion Operating Power Supply: 24VDC Operating Temperature: 0℃ to +55℃ Mounting Type: DIN‑rail rack mounting Indicator: Multi‑group status LED indicator
Functional Features
Integrated mixed I/O reduces the need for expansion modules in small to medium applications. The CS31 interface enables distributed I/O architectures over long cable distances (up to 1000 m shielded). Built-in real-time clock supports time-stamped event logging. High-speed counters can directly interface with encoders and flow meters. Optional fieldbus modules expand connectivity to PROFIBUS, Modbus, CANopen, and Ethernet networks.
Application Scenarios
Decentralized automation systems in water treatment, building management, and machine control. Standalone PLC applications requiring integrated analog I/O and fieldbus connectivity. Master or slave node in CS31-based distributed control architectures.
Installation and Usage Notes
Mount on a 35 mm DIN rail or directly via screws in a control cabinet. Connect the 24 V DC supply to the designated terminals observing polarity. Wire digital inputs observing the group isolation boundaries (ZP0, ZP1, ZP2). Connect analog signals with shielded cables, grounding the shield at the cabinet side. Configure I/O mapping, communication parameters, and high-speed counter modes in ABB Control Builder. Insert optional communication modules into the dedicated expansion slots as required.
