Technical Specifications Back‑plane bus interface, program memory, CS31 fieldbus communication port. Auxiliary power 24 V DC, typical power consumption 7.5 W. Operating temperature 0 ℃ to +60 ℃, storage temperature ‑40 ℃ to +85 ℃, non‑condensing relative humidity 5%‑95%.
Functional Features Loads and executes user PLC application logic program. Reads status data from each I/O module via back‑plane bus. Executes interlock, sequence and protection logic calculation. Supports CS31 fieldbus communication with remote I/O stations. On‑board LED displays running, standby and fault status. Built‑in hardware self‑diagnosis detects processor, memory and bus hardware faults.
Application Scenarios CPU spare part for ABB CS31 PLC automation system. Applied in factory production automation, water treatment and industrial auxiliary control system maintenance.
Performance Parameters Stable real‑time logic program execution performance. Reliable data interaction with I/O and remote stations. Accurate hardware fault self‑diagnosis capability.
Material Composition Flame‑retardant plastic module housing. Multilayer glass‑fiber epoxy printed circuit board. Industrial processor chip, memory and peripheral logic assemblies. Back‑plane plug‑in connector and fieldbus communication port.
Structural Characteristics Standard rack plug‑in module structure. Front panel equipped with status LED indicators and communication port. Rear side fitted with back‑plane bus connector. Weight approximately 0.69 kilogram.
Working Principle After power‑on, module completes hardware self‑test and system initialization. User control logic program is loaded from internal memory. It collects input‑output data through back‑plane bus, executes logic calculation, and outputs control commands. It completes data exchange with remote I/O stations via CS31 bus. Diagnosis circuit monitors module hardware running status continuously.
Installation Requirements Cut off controller rack auxiliary power before replacement. Insert 07KR31 FPR3600227R120 into designated CPU slot and lock fixing latch. Confirm back‑plane connector is fully engaged. Restore power supply, download user logic program and configuration parameters, verify control logic and fieldbus communication function.
