Technical Specifications 24VDC powered from carrier. 32 configurable channels. Support 4-20mA AI/AO, 24VDC DI/DO and pulse input. Built-in HART 7 coupler. Per-channel short-circuit protection. Operating temperature:0°C ~ +60°C.
Functional Features Software configurable channel type. HART pass-through for analog instruments. SOE sequence of event timestamp support. Per-channel short-circuit limiting. Field wiring termination.
Application Scenarios Chemical, pharmaceutical, small process unit, flexible I/O cabinet where channel types may change during project modification.
Performance Parameters High flexibility of channel configuration, HART communication, SOE 1ms time resolution. Operating temperature:0~+60°C.
Structural Characteristics 9-inch IOTA PCB board, dual-row compression screw terminals, backplane connector mating with CC-PUIO31 universal IOM, multi-function signal conditioning circuit.
Working Principle Each channel can be assigned by software as analog input, analog output, digital input, digital output or pulse input. The IOTA routes field signals and couples HART data between field instruments and universal IOM module.
Installation Requirements Mount on Series-C carrier rack. Connect field shielded cables. Define each channel function in Honeywell Control Builder software.
Usage Notes Confirm channel configuration before applying field power. Separate analog and digital signal wiring.
