Technical Specifications 24VDC power input. Multiple FTE Ethernet ports. Controller backplane interface. Operating temperature:0°C ~ +60°C.
Functional Features FTE network connection for C300 controller. Power distribution to controller module. Communication signal termination. Link status LED indicators.
Application Scenarios Experion PKS C300 controller rack, used for connecting controller to FTE control network.
Performance Parameters Stable FTE redundant network communication, reliable power feed to controller. Operating temperature:0~+60°C.
Structural Characteristics IOTA PCB board, multiple RJ45 FTE ports, power terminals, mating connector for C300 controller module.
Working Principle Deliver 24VDC power to C300 controller, and provide physical FTE Ethernet interface for controller to exchange data with HMI, other controllers and I/O network.
Installation Requirements Install in C300 control rack. Insert C300 controller module onto CC-TCNT01. Connect FTE network cables and 24VDC power.
Usage Notes Verify FTE network redundancy after power on. Do not hot swap controller while critical process is running.
