Technical Specifications Backplane power supply. Configurable universal I/O channels. Support analog and digital signal types. Galvanic isolation. Operating temperature:0°C ~ +60°C.
Functional Features Multi-type signal acquisition and control output. Channel function configurable by software. Fault diagnosis per channel. LED status indication. Hot swap.
Application Scenarios Chemical, pharmaceutical, small process unit, flexible I/O point configuration for DCS control cabinet.
Performance Parameters Flexible channel configuration, high signal precision. Operating temperature:0~+60°C.
Structural Characteristics Rack plug-in universal I/O module, front multi-function terminal block, backplane bus connector, integrated signal processing circuit.
Working Principle Each channel can be configured as analog/digital input or output via software. Collect field signals or output control commands and exchange data with C200 controller over backplane bus.
Installation Requirements Install into C200 I/O rack. Connect field instrument cables. Define each channel function in Honeywell engineering software.
Usage Notes Confirm channel configuration before applying field power. Separate analog and digital signal wiring.
