Technical Specifications Backplane powered. High-density digital output channels. Isolated channel group design. Operating temperature:0°C ~ +60°C.
Functional Features Mass discrete control signal output. Channel fault monitoring. Overload protection. LED status indication. Hot swap support.
Application Scenarios Petrochemical, power auxiliary system, large interlock system for valve and auxiliary equipment control.
Performance Parameters High channel integration, stable switching performance. Operating temperature:0~+60°C.
Structural Characteristics Rack plug-in I/O module, front wiring terminal block, backplane bus connector, multi-channel drive circuit.
Working Principle Receive digital logic commands from DCS controller, control each output channel on/off state to drive field relays and solenoid valves for interlock and sequence control.
Installation Requirements Insert module into Experion PKS rack. Connect field load cables. Complete hardware configuration download.
Usage Notes Check total load current of the module. Cut off load power before module replacement.
