Technical Specifications 24VDC power supply. 9 RJ45 FTE Ethernet ports: 8 downlink ports and 1 uplink port. Dual redundant FTE network support. Operating temperature:0°C ~ +60°C.
Functional Features FTE network cable termination. Network physical connection for control firewall module. Cabinet internal 24V power distribution. Network status LED indication.
Application Scenarios Experion PKS C300 DCS cabinet network segmentation, separating control zone and supervisory network for cyber security protection.
Performance Parameters High-speed FTE network transmission, redundant network path. Operating temperature:0~+60°C.
Structural Characteristics IOTA PCB board, 9 RJ45 Ethernet connectors, backplane connector for CC-PCF901, power distribution terminals.
Working Principle Provide physical Ethernet port interface for control firewall module. FTE network cables connect controllers and I/O nodes through CC-TCF901 to realize network traffic filtering and isolation.
Installation Requirements Install in Series-C carrier rack. Plug CC-PCF901 firewall module onto CC-TCF901. Connect FTE Ethernet cables to each RJ45 port.
Usage Notes Use certified FTE Ethernet cables. Keep network cables separated from high voltage power wiring.
