Technical Specifications Power supply: 24V DC. Digital input and output interfaces. Pulse command output. Operating temperature: 0°C ~ +55°C.
Functional Features High-speed pulse generation. Position closed-loop control. Axis fault monitoring. Built-in self-diagnosis. LED status indicators.
Application Scenarios Precision automation equipment, laser processing machines, pick-and-place manipulators and custom positioning platforms.
Performance Parameters Maximum pulse output frequency up to 4MHz. Position resolution 1 pulse. Operating temperature:0~+55°C.
Structural Characteristics Compact PCB control board, terminal blocks for signal wiring, status LED indicators, gold-plated connectors.
Working Principle Receive motion instructions from host controller, output pulse and direction signals to motor drive, read encoder feedback to complete closed-loop positioning.
Installation Requirements Install inside electrical cabinet. Follow ESD protection rules during installation. Separate signal cables from high-power cables.
Usage Notes Use anti-static wrist strap for maintenance. Avoid physical impact on circuit board. Keep the board clean and dry.
