Technical Specifications Power supply:24V DC. EtherCAT communication port. Support PACDrive C200 series I/O terminals. Operating temperature:0°C ~ +55°C. DIN rail mount.
Functional Features EtherCAT real-time bus protocol conversion. High-speed motion data transmission. Bus fault diagnosis. LED status indication for power, link and error. Support hot swap of I/O terminals.
Application Scenarios High-speed packaging machines, CNC processing equipment, robotic automation, multi-axis synchronous motion control production lines.
Performance Parameters Microsecond-level EtherCAT cycle time. High anti-interference performance. Operating temperature:0~+55°C.
Structural Characteristics DIN rail plastic housing, EtherCAT RJ45 ports, terminal contact rail, power terminals, front status LED array.
Working Principle Receive real-time motion commands from EtherCAT master controller, distribute data to local I/O terminals, collect field signal status and transmit back to master through EtherCAT bus.
Installation Requirements Install on standard 35mm DIN rail. Assemble I/O terminals sequentially behind the coupler. Connect 24V DC power and shielded EtherCAT cable.
Usage Notes Use shielded Ethernet cable for EtherCAT network. Check bus topology before commissioning. Avoid mixing incompatible terminal modules.
