Technical Specifications Power supply:24V DC. Analog signal input. Proportional current output. Operating temperature:0~+55°C.
Functional Features Analog signal conditioning. Proportional current drive for hydraulic valve. Gain and offset adjustment. Fault monitoring.
Application Scenarios Hydraulic press, injection molding machine, metal forming machine proportional hydraulic control.
Performance Parameters Adjustable output current. High signal linearity. Operating temperature:0~+55°C.
Structural Characteristics PCB amplifier board, potentiometer for parameter adjustment, signal terminals, LED indicators.
Working Principle Receive analog command signal from controller, convert to proportional drive current to control proportional valve spool position, regulate hydraulic flow and pressure.
Installation Requirements Install inside hydraulic control cabinet. Connect 24V power, command signal and proportional valve wiring.
Usage Notes Adjust gain and offset during commissioning. Protect board from hydraulic oil contamination.
