Technical Specifications Configurable 4-20mA / 0-10V signal. Multi-channel analog I/O. 12-bit resolution. Galvanic channel isolation. Power supply:24V DC. Operating temperature:0°C ~ +55°C.
Functional Features High precision analog signal sampling. Over-range and short-circuit detection. Per-channel fault diagnosis. LED channel status indication. Galvanic isolation to reduce noise interference.
Application Scenarios Pressure, temperature and flow signal acquisition, hydraulic proportional valve control, continuous process monitoring in packaging and machine tool automation.
Performance Parameters Measurement accuracy ±0.2%FS, 12-bit resolution. Operating temperature:0~+55°C.
Structural Characteristics DIN rail plug-in module, front LED indicators, field signal screw terminals, backplane bus connector for C200 rack.
Working Principle Convert field analog current/voltage signal into digital data and send to C200 controller; convert digital command from controller into analog signal to drive field actuators.
Installation Requirements Plug module onto PACDrive C200 terminal rail. Use shielded twisted pair for analog signal wiring. Separate analog cables from high-power cables.
Usage Notes Do not hot swap module with power applied. Perform channel calibration periodically. Prevent surge voltage on signal lines.
