Technical Specifications Power supply: 5V DC. Pulse resolution 1000ppr. Differential line driver output. Operating temperature: -20°C ~ +70°C.
Functional Features Incremental pulse output. Differential signal anti-interference. Shaft position and speed measurement. Compact housing.
Application Scenarios CNC machine tool, conveyor, motor speed feedback, rotating equipment position detection.
Performance Parameters 1000 pulses per revolution. Differential signal high noise immunity. Operating temperature:-20~+70°C.
Structural Characteristics Metal encoder housing, rotating shaft, internal optical code disc, cable connector.
Working Principle Optical code disc rotates with shaft, optical sensor generates A/B phase pulse signals, controller calculates rotation speed and position from pulse signals.
Installation Requirements Couple encoder shaft to measured shaft. Use shielded cable for signal wiring. Avoid radial overload.
Usage Notes Avoid mechanical impact on shaft. Prevent cable pulling. Check signal quality periodically.
