Technical Specifications Signal interface: BNC connectors. Digital and analog signal terminals. Operating temperature: 0°C ~ +50°C.
Functional Features Signal shielding and noise reduction. Multi-channel BNC signal access. Overvoltage protection. Screw terminal auxiliary connection.
Application Scenarios Laboratory measurement, industrial data acquisition, vibration and voltage signal test.
Performance Parameters High signal shielding performance. Bandwidth up to MHz level. Operating temperature:0~+50°C.
Structural Characteristics Metal shielded housing, multiple BNC front connectors, ribbon cable port, screw terminals.
Working Principle Transmit analog and digital signals from DAQ card to BNC ports, shield electromagnetic interference to guarantee measurement signal quality.
Installation Requirements Connect ribbon cable to NI DAQ device. Fix terminal block on workbench or cabinet. Complete shielding grounding.
Usage Notes Use 50Ω or 75Ω matched BNC cable. Avoid high voltage input exceeding rated range.
