Technical Specifications Power supply: 24V DC. UV flame signal input. Relay output. Operating temperature: 0°C ~ +60°C.
Functional Features Flame signal amplification and filtering. Flame presence detection. Loss-of-flame alarm relay output. Self-check function. LED indication.
Application Scenarios Industrial boiler, furnace, gas burner combustion safety monitoring.
Performance Parameters Flame detection response time <1s. Operating temperature:0~+60°C.
Structural Characteristics DIN rail mount housing, flame sensor input terminal, relay output terminal, power terminal, status LED.
Working Principle Receive weak UV signal from flame sensor, amplify and judge flame status. If flame signal disappears, trigger relay alarm and send trip signal to burner controller.
Installation Requirements Install inside burner control cabinet. Connect UV flame scanner and power wiring.
Usage Notes Regularly test flame detection function. Do not bypass safety interlock circuit.
