Technical Specifications Power supply: 24V DC. EtherCAT interface. Supports KL series I/O terminals. Operating temperature: -25°C ~ +60°C.
Functional Features EtherCAT bus protocol conversion. Local I/O data collection and transmission. Bus fault diagnosis. LED status indication. Hot swap of terminals.
Application Scenarios Factory automation, packaging machine, production line distributed I/O control.
Performance Parameters EtherCAT cycle time in microsecond level. Supports up to 64 terminals. Operating temperature: -25 ~ +60°C.
Structural Characteristics DIN rail mounted bus coupler, EtherCAT RJ45 port, terminal contact rail, power terminals, status LEDs.
Working Principle Receive EtherCAT command from PLC master, exchange data with connected KL I/O terminals, transmit I/O status back to master controller via EtherCAT network.
Installation Requirements Install on 35mm DIN rail. Assemble I/O terminals sequentially. Connect 24V DC power and EtherCAT network cable.
Usage Notes Use standard EtherCAT shielded cable. Check bus topology. Do not mix incompatible terminal modules.
