Technical Specifications Coil voltage configurable. 8 contact points. Contact rating: 250VAC / 5A. Operating temperature: -25°C ~ +70°C. DIN rail mountable.
Functional Features Multiple contact configuration. Fast switching response. Mechanical status indicator. High dielectric strength. Suitable for power protection cabinet.
Application Scenarios Power substation relay protection cabinet, generator control panel, high voltage switchgear signal interlock.
Performance Parameters Operate time <20ms. Insulation voltage 2kV AC. Operating temperature: -25 ~ +70°C.
Structural Characteristics Standard relay plastic housing, coil terminals, contact terminals, mechanical action indicator window.
Working Principle When coil is energized, electromagnetic force pulls armature to switch contact state, realizing connection or disconnection of external control circuits.
Installation Requirements Clip onto standard 35mm DIN rail. Wire coil and contact terminals strictly according to schematic diagram.
Usage Notes Do not exceed rated contact load. Check contact ablation regularly in frequent switching applications.
