Technical Specifications 8‑channel digital input, rated input signal 24 V DC. Back‑plane controller bus interface. Auxiliary power 24 V DC, typical power consumption 2.9 W. Operating temperature 0 ℃ to +60 ℃, storage temperature ‑40 ℃ to +85 ℃, non‑condensing relative humidity 5%‑95%. Channel‑group galvanic isolation.
Functional Features Acquires on‑off status of field 24 V DC digital contact signals. Completes signal isolation and level conversion. Transmits 8‑channel status data to main controller via back‑plane bus. Front‑panel LED indicators show real‑time status of each input channel. Built‑in hardware self‑diagnosis detects internal circuit failure.
Application Scenarios Digital input spare part for ABB Advant DCS system. Applied in discrete‑signal acquisition cabinet maintenance of process‑industry sites.
Performance Parameters Fast digital signal response speed. Independent channel status indication. Stable bus data transmission performance.
Material Composition Flame‑retardant plastic module housing. Multilayer glass‑fiber epoxy printed circuit board. Signal isolation and level conversion assemblies. Back‑plane plug‑in connector and field signal terminals.
Structural Characteristics Standard rack plug‑in module. Front side fitted with field digital signal terminals and channel status LED indicators. Rear side equipped with back‑plane bus connector. Weight approximately 0.29 kg.
Working Principle Field 24 V DC switching signals access each channel terminal. Internal isolation circuit completes signal level conversion. Channel status data is encoded and uploaded to controller via back‑plane bus. Diagnosis circuit monitors module internal hardware operating condition continuously.
Installation Requirements Cut off rack auxiliary power before replacement. Insert DSTD108 into corresponding rack slot and lock fixing latch. Connect field digital signal wiring to front‑end terminals. Ensure back‑plane connector is fully engaged. Restore power supply, verify input response of all 8 channels.
Usage Notes Prevent over‑voltage surge signal from accessing input channels. Keep field wiring polarity correct. Hot‑plug under powered state is forbidden. Test signal response of every channel after module replacement.
