Technical Specifications High‑voltage and high‑current rated parameters, integrated gate driving interface. Operating junction temperature ‑40 ℃ to +125 ℃, storage temperature ‑40 ℃ to +125 ℃. Press‑pack mechanical structure.
Functional Features Executes high‑power main circuit switching operation for power conversion system. Completes fast turn‑on and turn‑off action under gate signal control. Realizes energy conversion for inverter and rectifier circuit. Supports high‑current continuous working condition.
Application Scenarios Power semiconductor spare part for ABB large‑size frequency converter, static excitation and power inverter equipment. Widely applied in metallurgy, energy industry high‑power electronic equipment maintenance.
Performance Parameters Fast switching response speed. High‑current conduction capability. Stable thermal performance under long‑time continuous operation.
Material Composition Press‑pack metal electrode housing. Semiconductor silicon wafer chip. Gate signal terminal. High‑strength insulating structural components.
Structural Characteristics Press‑pack disc‑type power device. Main power electrode on both end faces, gate signal terminal on side face. Installed by stacking pressing mode. Weight approximately 1.3 kilogram.
Working Principle Gate control signal triggers device turn‑on to pass high‑current main‑loop power. Reverse gate commutated signal forces device turn‑off to cut‑off main‑loop current. Device completes repeated high‑power switching actions to realize AC‑DC‑AC energy conversion.
Installation Requirements Completely cut off main power and discharge internal high‑voltage capacitor before replacement. Install 5SHX2645L0006 into power stack, apply specified pressing force evenly. Complete main power electrode contact and gate signal wiring. Restore equipment power supply and perform high‑voltage withstand test and equipment running test.
Usage Notes Strictly complete capacitor discharge procedure before disassembly and assembly. Maintain specified stacking pressure during installation. Protect gate terminal from electrostatic damage. Verify gate driving circuit performance after device replacement.
