Technical Specifications Industrial embedded hardware structure, internal non‑volatile memory, multiple bus interface. Auxiliary power 24 V DC. Operating temperature 0 ℃ to +55 ℃, storage temperature ‑40 ℃ to +85 ℃, non‑condensing relative humidity 5%‑95%.
Functional Features Loads and runs robot operating system and user application program. Completes robot motion trajectory planning and kinematics calculation. Sends motion commands to servo drive modules. Stores robot system configuration, mechanical parameters and user programs. On‑board LED indicates unit running and fault status. Built‑in hardware self‑diagnosis detects processor, memory and bus hardware faults.
Application Scenarios Core control spare‑part for ABB industrial robot controller cabinet. Applied in automated production line robot main control unit failure replacement.
Performance Parameters High‑speed real‑time robot motion trajectory calculation. Reliable storage for system parameters and user programs. Accurate hardware fault self‑diagnosis capability.
Material Composition Metal shielding housing. Multilayer industrial‑grade printed circuit board, embedded processor chip and memory assemblies. Internal bus connectors and external interface sockets.
Structural Characteristics Cabinet plug‑in installation unit. Equipped with internal bus connectors and external interface ports. Fixed mounting holes. Weight approximately 1.4 kilogram.
Working Principle After power‑on, unit completes hardware self‑test and robot system software loading. It reads robot mechanical parameters and user programs. Motion trajectory planning and kinematics calculation are executed, and motion commands are sent to each servo drive module via internal bus. Diagnosis circuit monitors hardware running state continuously.
Installation Requirements Cut off robot cabinet total power supply before replacement. Insert 3HAC024144‑001 into designated cabinet slot and fasten fixing screws. Confirm internal bus connectors are fully engaged. Restore power supply, install robot system software, import mechanical parameters and user programs, complete robot zero‑point calibration and overall motion test.
