Technical Specifications
24VDC power supply, magnetic pickup speed input, proportional actuator drive output. Operating temperature: -40℃ ~ +70℃.
Functional Features
Speed PID control, load sharing function, speed ramp, overspeed protection and fault diagnosis.
Application Scenarios
Diesel generator parallel system, gas engine power station and industrial drive prime movers.
Performance Parameters
Accurate load balance, low steady-state error, strong anti-interference ability.
Structural Characteristics
Integrated panel controller, terminal block, multi-group LED status indicators.
Working Principle
The controller continuously compares feedback speed with setpoint, calculates the adjustment output, and controls the fuel actuator to eliminate speed deviation.
Installation Requirements
Shielded twisted-pair wire for speed signal, separate signal wiring and power wiring.
Usage Notes
Back up all configured parameters after debugging to avoid repeated setting after replacement.
