24VDC power supply, magnetic pickup speed input, proportional actuator drive output. Operating temperature: -40℃ ~ +70℃.
Functional Features
Speed closed-loop regulation, overspeed alarm and trip, startup fuel limit, fault self-diagnosis.
Application Scenarios
Land generator sets, industrial drive prime movers and small marine auxiliary engines.
Performance Parameters
Quick regulation response, adjustable speed droop, stable actuator driving capacity.
Structural Characteristics
Panel-mounted controller, wiring terminal block, running and fault LED indicators.
Working Principle
The controller compares the actual speed from pickup with preset speed setpoint, calculates correction signal and drives fuel actuator to stabilize engine speed.
Installation Requirements
Mount on shock absorption bracket, shielded twisted-pair cable for speed sensor wiring.
Usage Notes
Calibrate actuator stroke before commissioning, set overspeed threshold according to engine specification.
