Technical Specifications
24VDC power supply, magnetic pickup speed input, proportional drive output. Operating temperature: -40℃ ~ +70℃.
Functional Features
Closed-loop PID speed control, overspeed protection, soft startup ramp, fault detection and status output.
Application Scenarios
Emergency backup diesel gensets, pumping station prime movers and unattended power supply units.
Performance Parameters
Reliable protection action, low maintenance requirement, strong environmental adaptability.
Structural Characteristics
Panel-mounted integrated controller, terminal wiring area, status indicator lamps.
Working Principle
The speed signal from magnetic pickup is converted to speed value. When speed deviates from target, the controller adjusts fuel actuator to restore stable speed.
Installation Requirements
Install in well-ventilated cabinet, prevent dust and moisture from entering the controller.
Usage Notes
Verify overspeed shutdown function periodically during routine maintenance.
