Technical Specifications
24VDC power supply, magnetic pickup speed input, proportional actuator drive output. Operating temperature: -40℃ ~ +70℃.
Functional Features
Speed closed-loop control, startup ramp limiting, overspeed protection, fault alarm and status indication.
Application Scenarios
Emergency backup diesel generators, pumping station prime movers and light-duty industrial drive engines.
Performance Parameters
Reliable protection action, simple parameter configuration, stable continuous operation.
Structural Characteristics
Integrated panel controller, wiring terminals, running and fault LED indicators.
Working Principle
The speed feedback signal is compared with the target setpoint. The internal regulation algorithm outputs proportional current to adjust the fuel actuator opening.
Installation Requirements
Avoid high-temperature and oil-mist dense installation positions, reserve sufficient heat dissipation space.
Usage Notes
Regularly check the air gap of the magnetic pickup and the integrity of signal wiring.
