Technical Specifications Supply voltage:24 V DC ±10%; Control signal:4–20mA; Position feedback:4–20mA; Operating pressure:0.5–10 bar(g); Operating temperature:-40 °C ~ +130 °C; Enclosure:IP65.
Functional Features Wide high temperature range; high temperature resistant seals; closed-loop LVDT feedback; low thermal drift.
Application Scenarios Engine compartment direct mount, high ambient temperature gas engine, heavy-duty industrial genset.
Performance Parameters Flow linearity:±2.2% FS; Repeatability:±1% FS; Response time:<22 ms.
Material Composition Aluminum valve body; stainless steel internals; high temperature FKM seals; high temperature LVDT and solenoid coil.
Structural Characteristics Inline flow body; high temperature resistant top electronic and solenoid assembly; threaded process ports.
Working Principle 4–20mA control signal sets target opening, LVDT provides real-time position feedback. High temperature material reduces position drift under high ambient temperature.
Installation Requirements Install inline vertically; isolate valve body from excessive radiant heat if possible; calibrate after thermal stabilization.
Usage Notes Do not exceed maximum continuous temperature rating; inspect high temperature seals periodically.
