Technical Specifications Supply voltage:24 V DC ±10%; Control signal:4–20mA; Position feedback:4–20mA; Operating pressure:0.3–8 bar(g); Operating temperature:-30 °C ~ +115 °C; Enclosure:IP65.
Functional Features Compact dimension; closed-loop LVDT feedback; low power consumption; linear flow curve; zero shutoff.
Application Scenarios Small gas generator, packaged cogeneration unit, compact engine control cabinet, mobile gas power equipment.
Performance Parameters Flow linearity:±2.2% FS; Repeatability:±1% FS; Response time:<20 ms.
Material Composition Miniature aluminum valve body; stainless steel plunger; FKM seals; compact LVDT sensor; small solenoid coil.
Structural Characteristics Small inline valve body; compact top solenoid and sensor assembly; compact threaded process ports.
Working Principle 4–20mA analog signal defines target opening. LVDT feeds back plunger position, control circuit adjusts solenoid current to maintain required opening.
Installation Requirements Install inline; reserve enough installation space; connect analog signal and power; perform calibration.
Usage Notes Check gas medium cleanliness; protect compact electronic part from mechanical impact.
