Technical Specifications Supply voltage:24 V DC ±10%; Communication:EtherNet/IP 10/100Mbps; Operating pressure:0.5–10 bar(g); Operating temperature:-30 °C ~ +120 °C; Enclosure:IP65; Position resolution:16-bit.
Functional Features EtherNet/IP communication; embedded web server; LVDT closed-loop control; remote configuration and diagnostic; data logging.
Application Scenarios Ethernet-based smart power plant, IIoT gas generator, remote monitoring cogeneration engine, industrial internet fuel control.
Performance Parameters Flow linearity:±2% FS; Repeatability:±0.8% FS; Communication cycle:10 ms.
Material Composition Aluminum valve body; stainless steel internals; FKM seals; EtherNet/IP controller board; LVDT sensor.
Structural Characteristics Inline flow body; top-mounted solenoid and Ethernet electronic unit; RJ45 sealed Ethernet connector.
Working Principle EtherNet/IP master sends target opening command. Onboard controller compares LVDT real position, adjusts solenoid current, upload valve status and diagnostic data via Ethernet.
Installation Requirements Install inline vertically; connect Ethernet and 24V power; set IP address; calibrate zero and span.
Usage Notes Use industrial shielded Ethernet cable; implement network security access control; backup valve configuration regularly.
